Network Standard

IEEE 802.3af/at/bt, IEEE 802.3 10Base-T, 100Base-TX, 1000Base-T, 10GBASE-X

Speed & Duplex

100Mbps/1Gbps: Half/Full Duplex Auto-negotiation; 2.5G/5G/10Gbps: Full Duplex

Port Feature

Auto-MDI/MDI-X

Forwarding Mode

Store-and-Forward

Switching Capacity

20Gbps

Jumbo Frame

9K Bytes

MAC Address Table

16K entries, automatic address learning & aging

PoE Standard

IEEE 802.3af/at/bt

Cable Requirement

10G: Cat6A/Cat7; 5G: Cat6/Cat6A/Cat7; 1G/2.5G: Cat5e/Cat6/Cat6A; 100M: Cat5/Cat5e/Cat6; Max 100m over 100Ω UTP/STP

Fiber Compatibility

Multimode: 50/125μm, 62.5/125μm, up to 300m; Single-mode: 9/125μm

Optional SFP+ Module

Wavelength: 1310nm/1550nm; Distance: 2KM/10KM/20KM/40KM/80KM

Input Power

48~57VDC, 4-pin Terminal Block, Redundant Power

Max Power Consumption

35W

Protection

Overload Automatic Resettable, Reverse Polarity Protection

DIP Switch

4-digit DIP switch, customized function available

Enclosure

IP40 Aluminum Alloy Case

Installation

DIN-Rail / Wall-mount

Dimension (W×D×H)

95 × 70 × 30 mm

Weight

0.25Kg

Operating Temperature

-40°C ~ 80°C

Storage Temperature

-40°C ~ 85°C

Relative Humidity

5%~95% Non-condensing

MTBF

>200,000 hrs

EMC Compliance

EN55022, EN55024, IEC 61000-4-2/3/4/5/6/8
