8 Port Fast Ethernet Switch 10/100Mbps Desktop LAN Switch IP30

8-port 10/100BASE-T RJ45 with auto MDI / MDI-X function

5VDC Input

￥ 0.00

Product Description

8-port 10/100BASE-T RJ45 with auto MDI / MDI-X function

5VDC Input

This 8-port fast Ethernet switch is a compact desktop networking device equipped with 8 auto-adaptive 10/100Base-TX RJ45 data ports, fully compliant with mainstream IEEE Ethernet protocols. It adopts store-and-forward wire-speed forwarding architecture to deliver stable and efficient data transmission, ideal for home networks, small offices, retail stores and surveillance systems.

8-Port 10/100M auto adaptive RJ45 ports
1.6Gbps bandwidth, wire-speed store-and-forward
1K MAC address table & 768K buffer
Low standby power ≤3W, DC 5V external power
Wide working temp -10℃~55℃, IP30 dustproof
Plug & play desktop design

Smart Home Network Small Factory Monitoring 🏠 🏭 \ / \ / ▼ ▼ ┌─────────────────────────────────────────────┐ │ 8 Port Fast Ethernet Switch └─────────────────────────────────────────────┘ / | \ / | \ ▲ ▲ ▲ Home Terminals Office Equipment CCTV Surveillance PC/TV/Game Console POS/Printer/Laptop 100M IP Cameras ▲ | Central Control Terminal (Router / NVR / Office Host)

Product	8 Port Fast Ethernet Switch
Fixed Port	8*10/100Base-TX RJ45 port (Data)
Network Protocol	IEEE 802.3 IEEE 802.3i 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3x
Port Specification	10/100BaseT(X)Auto
Transmission Mode	Store and Forward(full wirespeed)
Bandwidth	1.6Gbps
Packet Forwarding	1.15Mpps
MAC Address	1K
Buffer	768K
Transmission Distance	10BASE-T ： Cat3,4,5 UTP(≤250 meter) 100BASE-TX ： Cat5 or later UTP(150 meter)
Watt	Standby Power Consumption：≤3W；
LED Indicator	PWR:Power LED 1-8：(Link LED=10/100M Link)
Power	External Power DC：5V
Operating Temperature/Humidity	-10～+55°C；5%～90% RH Non coagulation
Storage Temperature/Humidity	-40～+75°C；5%～95% RH Non coagulation
Product size/Packing size（LWH）	125mm60mm24mm 131mm70mm65mm
N.W/G.W（kg）	0.3kg/0.5kg
Installation	Desktop
Lightning protection level	IP30
Certificate	CE FCC RoHS
Warranty	Whole device for 3 year(Accessories not included)
