3-Port 100Mbps PoE Extender 30W IEEE802.3af/at

Model:WXA-AT13F-A

1*IEEE802.3af/at (PoE) powered port input

3*IEEE802.3af/at (PoE) powered port output

With network and POE relay extension role

￥ 0.00

Product Description

Model:WXA-AT13F-A

1*IEEE802.3af/at (PoE) powered port input

3*IEEE802.3af/at (PoE) powered port output

With network and POE relay extension role

WXA-AT13F-A is a 100Mbps Ethernet PoE Extender, which provides 1*100Mbps IEEE802.3af/at(PoE) powered port input and 3*1000Mbps IEEE802.3af/at(PoE) powered ports output. The whole power is 30W, and the average output power is 8W per port.

1*IEEE802.3af/at (PoE) powered port input
3*IEEE802.3af/at (PoE) powered port output
With network and POE relay extension role
Support Din-rail mounting

Network Standard	IEEE 802.3、IEEE 802.3u、IEEE 802.3x
Port	310/100Mbps RJ45 power supply port 110/100Mbps RJ45 receiving port
POE Power	The whole power is 30W Output power of single port is 24W, average output power per port is 8W
POE Connection	POE input receiving wire core：1/2+、3/6- 、4/5+、7/8- POE output power supply core：1/2+、3/6- 100M Transmission
Performance	Store and forward MAC address table 1k Switching capacity 1.6Gbps
Forwarding Rate	10BASE-T:14880PPS/port 100BASE-tx：148800pps/port
Port Function	Power priority mechanism, fast and forward, MAC automatic learning and aging IEEE802.3X Full-duplex and backpressure for half-duplex mode
Environment	Operating Temperature：-10℃ - -55℃
Power	Input：DC44-57V，30W；Output：DC44-57V，24W
Weight &Size	55g 95mm×130mm×35mm(L×W×H)
